Product Description
Light weight and portable design, no need electric and air pressure
Both side open design, no width limited
Single finger splice & double fingers splice
Standard blade 15*75mm or 20*50mm
Features and Benefits:
Portable, manual and easy handling
No electricity or pressure required
Open ended for wider conveyor belts
Single or Finger over finger punching
Accessories and options
Standard blade is 15*75mm for single finger or 20*50mm for finger over finger
10*80mm, 20*80mm and other fingers can be custom-made
Bias punching board can be custom-made
| Size | TC1200 |
| Machine Length | 1450mm |
| Machine width | 390mm |
| Machine height | 380mm |
| Weight | 41kgs |
| Packing weight | 74kgs |
| Packing Dimension | 1540*500*540mm |
