Homogeneous Belt Joint Machine PD600-1200
Homogeneous Belt Finger Joint Machine
For PU & Homogeneous Conveyor Belts
Manual hydraulic finger jointing with stable, clean cutting.
-
Homogeneous Belt Compatible
Clean finger joints without material tearing. -
Manual Hydraulic Press
One-person operation, no power supply. -
On-Site & Small-Batch Use
Ideal for maintenance and repair work. -
Interchangeable Finger Molds
Supports different finger profiles. -
Mechanical Safety Stop
Stable positioning and safe operation.
Application Areas
Technical Specifications
| Machine Parameters | PD 600 | PD 900 | PD 1200 |
|---|---|---|---|
| Heating Rod Power | 1.35KW | 1.8KW | 2.35KW |
| Voltage | 220V | 220V | 220V |
| Maximum Temperature | 300℃ | 300℃ | 300℃ |
| Applicable Belts | Special-shaped Belts | Special-shaped Belts | Special-shaped Belts |
| Belt Jointing Time | 3-5min | 3-5min | 3-5min |
| Minimum Belt Thickness | 0.8mm | 0.8mm | 0.8mm |
| Maximum Belt Thickness | 5mm | 5mm | 5mm |
| Effective Heating Width | 700mm | 1000mm | 1300mm |
| Accessories Included | PTFE Tape (One Roll) | PTFE Tape (One Roll) | PTFE Tape (One Roll) |
| Heating Duration | Heating: 6 seconds, Insulation: 10 seconds | Heating: 6 seconds, Insulation: 10 seconds | Heating: 6 seconds, Insulation: 10 seconds |
| Cooling Medium | Natural Cooling | Natural Cooling | Natural Cooling |
| Machine Weight | 38kg | 47kg | 56kg |
| Specifications | 1020*335*250mm | 1320*335*250mm | 1620*335*250mm |
| Note: Suitable for various types of toothed belts; not applicable to flat belts. | |||
Why Choose HOLO
Hygienic Belt Jointing Solutions You Can Trust
HOLO develops belt processing equipment with a strong focus on clean design, process efficiency, and application accuracy.
-
Fast and clean butt jointing process
-
Designed for food-grade and homogeneous belts
-
Accurate template-based joint control
-
Reduced downtime and easy operation
-
Stable performance for continuous production
Although manufactured in China, HOLO machines are designed and tested to benchmark the quality standards of leading European and American brands, particularly in hygiene-sensitive applications.
Quality Control & Factory Inspection
Dual Inspection System
Each PD600–1200 homogeneous belt joint machine undergoes:
-
Pre-storage inspection after assembly
-
Pre-shipment inspection before delivery
This ensures stable heating performance, accurate joint alignment, and reliable operation.
After-Sales Service & Support
-
Warranty: 1 year
-
Support Services: Installation guidance, operator training, and technical consultation
-
Special Applications: HOLO engineering team supports customized belt jointing solutions
FAQ & Support
Q1: What types of belts is this machine designed for?
A: It is designed specifically for homogeneous conveyor belts, commonly used in food and hygiene industries.
Q2: How long does one jointing cycle take?
A: The full process takes less than 20 minutes, with actual jointing time as short as 3–5 minutes.
Q3: How is joint accuracy ensured?
A: Interchangeable templates ensure accurate cutting length and correct belt pitch.
Q4: Is the joint suitable for hygienic applications?
A: Yes. The clean joint design meets the requirements of hygiene-sensitive environments.
Q5: Can HOLO support customized belt jointing needs?
A: Yes. Our engineering team can assist with customized applications and belt specifications.
