Sectional Rubber Conveyor Belt Vulcanizing Press
Compact and Versatile Vulcanizing Solution for Rubber Conveyor Belts
Key Features
Aluminum alloy frame: lightweight and compact
Electric heating blanket design: thin, uniform heating plate
Pure rubber hydraulic bags: high-pressure resistant and leak-proof
Fully automatic electric control: set parameters and operate
Suitable for normal, corrosion-resistant, heat-resistant, and long/high-strength belts
Applicable across metallurgy, mining, and multiple industrial sectors
For belt type, width, and vulcanizing requirements, please submit your details via the contact form.
Application Areas
Technical Specifications
| Model | Width of Vulcanized Belt | Spexification | Size of heating plate | Power | Dinemsion | Weight |
|---|---|---|---|---|---|---|
| XS/DGLJL-650 | 650mm | 650x830mm | 830×820mm | 9.8kw | 1140×830×585mm | 440kg |
| 650x1000mm | 1000×820mm | 11.8kw | 1140×1000×585mm | 530kg | ||
| XS/DGLJL-800 | 800mm | 800x830mm | 830×995mm | 11.97kw | 1320×830×585mm | 515kg |
| 800x1000mm | 1000×995mm | 14.4kw | 1320×1000×585mm | 630kg | ||
| XS/DGLJL-1000 | 1000mm | 1000x830mm | 830×1228mm | 14.7kw | 1450×830×585mm | 600kg |
| 800x1000mm | 1000×1000mm | 17.8kw | 1450×1000×585mm | 715kg | ||
| XS/DGLJL-1200 | 1200mm | 1200x830mm | 830×1431mm | 17.2kw | 1700×830×750mm | 800kg |
| 1200x1000mm | 1000×1431mm | 20.7kw | 1700×1000×750mm | 850kg | ||
| XS/DGLJL-1400 | 1400mm | 1400x830mm | 830×1653mm | 19.8kw | 1950×830×750mm | 900kg |
| 1400x1000mm | 1000×1653mm | 23.8kw | 1950×1000×750mm | 950kg | ||
| XS/DGLJL-1600 | 1600mm | 1600x830mm | 830×1867mm | 22.3kw | 2150×830×795mm | 1100kg |
| 1600x1000mm | 1000×1867mm | 27kw | 2150×1000×790mm | 1150kg | ||
| XS/DGLJL-1800 | 1800mm | 1800x830mm | 830×2079mm | 24.9kw | 2380×830×900mm | 1500kg |
| 1800x1000mm | 1000×2079mm | 30kw | 2380×1000×900mm | 1800kg | ||
| XS/DGLJL-2000 | 2000mm | 2000x830mm | 830×2303mm | 27.6kw | 2620×830×900mm | 1810kg |
| 2000x1000mm | 1000×2303mm | 33.2kw | 2620×1000×900mm | 2160kg | ||
| XS/DGLJL-2200 | 2000mm | 2200x830mm | 830×2478mm | 29.7kw | 2830×830×900mm | 2040kg |
| 2200x1000mm | 1000×2478mm | 35.8kw | 2830×1000×900mm | 2450kg |
Why Choose HOLO
HOLO provides conveyor belt vulcanizing equipment designed for precision, safety, and multi-industry application.
The sectional press is engineered to help factories and distributors achieve consistent belt joints while maintaining workflow efficiency.
Lightweight aluminum frame for easy installation and handling
Uniform heating ensures reliable vulcanization
High-pressure hydraulic bags guarantee joint strength
Adaptable for various rubber belt types and industrial applications
Quality Control & Factory Inspection
Each Sectional Rubber Conveyor Belt Vulcanizing Press undergoes inspection before shipment, including:
Frame stability and structural integrity check
Heating plate temperature uniformity testing
Hydraulic bag pressure and leak inspection
Electrical control system verification
Final operational inspection
After-Sales Service & Support
Installation guidance and operator training
Technical consultation for belt type, width, and vulcanizing parameters
Spare parts supply and long-term service support
Remote technical assistance available
FAQ & Support
Q1: What types of belts can this press vulcanize?
A: Suitable for normal rubber belts, corrosion-resistant, heat-resistant, and long/high-strength belts.
Q2: Is the machine easy to operate?
A: Yes. Fully automatic electric control allows one-time parameter setting and operation.
Q3: What is the frame material?
A: Aluminum alloy, making it compact and lightweight while maintaining structural strength.
Q4: Is the hydraulic bag reliable?
A: Yes. Made of pure rubber, resistant to high pressure, and leak-proof.
Q5: Can this machine be used in different industries?
A: Yes. Suitable for metallurgy, mining, and other industrial sectors.
