Pneumatic PVC PU Belt Finger Puncher TA1000-3200
High-Precision Pneumatic Finger Punching for PVC and PU Conveyor Belts
Key Features
High-efficiency punching plate ensures accurate finger formation
Sharp, durable blades for single or double finger punching
Air-driven operation: runs with an air pump, no electricity needed
Pneumatic-hydraulic booster cylinder provides high punching pressure and easy disassembly for transport
Optional punch plates available: pointed, diamond, or angled teeth
For belt type, width, and finger requirements, please submit your details via the contact form.
Application Areas
Technical Specifications
| Machine Name | Pneumatic Tooth Punching Machine 1.1m | Pneumatic Tooth Punching Machine 1.6m | Pneumatic Tooth Punching Machine 2.1m | Pneumatic Tooth Punching Machine 3.2m(Non-standard) |
|---|---|---|---|---|
| Applicable Belts | PU/PVC | PU/PVC | PU/PVC | PU/PVC |
| Maximum Standard Belt Thickness (mm) | 5 | 5 | 5 | 5 |
| Effective Width (m) | 1 | 1.6 | 2.1 | 3.2 |
| Specifications (mm) | 1220*515*1390 | 1770*515*1390 | 2370*515*1390 | 3470*515*1390 |
| Common Cylinder Working Pressure (MPa) | 0.4-0.8 | 0.4-0.8 | 0.4-0.8 | 0.4-0.8 |
| Maximum Output Force (T) | 3 | 3 | 3 | 3 |
| External Connection Pipe (mm) | diameter8 | diameter8 | diameter8 | diameter8 |
| External Connecting Pipe | diameter14mm | diameter14mm | diameter14mm | diameter14mm |
| Machine Weight | / | / | / | / |
| Weight Including Wooden Case (Kg)t | 150 | 190 | 230 | / |
| Standard Tooth Plate | 20*50 Arc Tooth | |||
Why Choose HOLO
HOLO provides pneumatic belt punching equipment designed for precision, efficiency, and mobility.
The TA1000–3200 is ideal for factories and distributors seeking high-quality finger punching with flexible, air-driven operation.
Air-powered operation reduces electrical dependency
High punching precision for consistent finger teeth
Optional blade types allow production flexibility
Easy to transport and install due to lightweight design and booster cylinder
Quality Control & Factory Inspection
Each Pneumatic PVC / PU Belt Finger Puncher undergoes inspection before shipment, including:
Punching accuracy and repeatability testing
Blade sharpness and durability check
Pneumatic and hydraulic pressure verification
Final operational inspection
After-Sales Service & Support
Warranty: 1 year
Service Scope: Installation guidance, operator training, and technical consultation
Complex Applications: Custom punch plates and belt specifications supported
FAQ & Support
Q1: What belt types can this puncher handle?
A: Suitable for PVC and PU conveyor belts of various widths.
Q2: Can it punch single and double fingers?
A: Yes. Supports both single and double finger punching.
Q3: Does it require electricity?
A: No. Air-driven operation only requires a compatible air pump.
Q4: How is high punching pressure achieved?
A: Through a pneumatic-hydraulic booster cylinder, ensuring accurate and consistent punching.
Q5: Are optional punch plates available?
A: Yes. Options include pointed, diamond, and angled teeth.
