Hydraulic Timing Belt Finger Punching Machine TBT260
Finger Punching Machine for Conveyor Belts
Precise finger pattern punching for conveyor belt splicing preparation.
-
Accurate Finger Forming
Consistent finger geometry for strong splices. -
Stable Punching Structure
Clean cuts without belt deformation. -
Easy & Safe Operation
Simple setup with operator protection. -
Wide Belt Compatibility
Suitable for various belt materials and widths. -
Workshop & On-Site Use
Compact design for flexible operation.
Application Areas
Technical Specifications
| Product Name | Timing Belt Tooth Punching Machine | |||||
|---|---|---|---|---|---|---|
| Body Specifications | 1150*600*1470 | |||||
| Weight | 400kg | |||||
| Hydraulic Station Power | 4kw | |||||
| Timing Belt Model | Tooth Profile Mold Customized Based on Requirements | |||||
| Thickness | 10mm | |||||
| Timing Belt Width | 200mm | |||||
| Maximum Hydraulic Pressure | 25T | |||||
| Control Method | Touch screen | |||||
Why Choose HOLO
Precision & Reliability for Timing Belt Processing
HOLO develops belt processing equipment with a focus on accuracy, safety, and production efficiency:
-
Hydraulic pressure ensures stable and precise punching
-
Movable platform improves operator safety and speed
-
Touch-screen interface for accurate, repeatable parameter settings
-
Width scale for precise belt adjustment
-
Durable and reliable for industrial production
Although manufactured in China, HOLO machines are engineered and tested to benchmark the quality standards of leading European and American brands, ensuring precise, safe, and reliable operation.
Quality Control & Factory Inspection
Dual Inspection System
Each Hydraulic Timing Belt Finger Punching Machine undergoes:
-
Pre-assembly inspection for hydraulic performance and mechanical accuracy
-
Pre-shipment inspection to ensure precise punching, platform stability, and touch-screen functionality
This guarantees consistent tooth placement, operational safety, and industrial reliability.
After-Sales Service & Support
-
Warranty: 1 year
-
Support Services: Installation guidance, operator training, and technical consultation
-
Special Applications: HOLO engineering team supports customized punching solutions
FAQ & Support
Q1: How is punching precision ensured?
A: Hydraulic pressure provides stable and sufficient force, ensuring precise and reliable tooth punching.
Q2: Is the machine safe and easy to operate?
A: Yes. Movable platform allows safe belt placement, and the touch-screen interface simplifies operation.
Q3: Can the machine handle different belt widths?
A: Yes. The integrated width scale allows accurate adjustment for various belt widths.
Q4: How is operation controlled?
A: Industrial touch screen allows visualized parameter settings, repeatable setup, and precise control.
Q5: Can HOLO customize the punching machine for special belts?
A: Yes. Our engineering team can provide tailored hydraulic punching solutions for specific belt requirements.
