Homogeneous Belt Splice Press PA600-1500

Portable Homogeneous Belt Splicing Solution

Designed for fast and reliable splicing of homogeneous conveyor belts with minimal setup.

All-in-One Integrated Design
No external components; stable and reliable operation.
Plug-and-Play Operation
Easy to use with no special training required.
Interchangeable Base Plates
Adapts to different homogeneous belt types.
Fast Splicing (8–25 min)
Improves efficiency and reduces downtime.
Strong & Clean Splice Joint
Durable, neat, and professional splice finish.
Portable with Carrying Case
Easy to transport for on-site applications.

Application Areas

Technical Specifications

Machine Model	PA 300	PA 600	PA 900	PA 1200	PA 1500	PA 1800H
Effective Length(mm)	300	600	900	1200	1500	1800
Effective Width(mm)	130
Upper Mold Weight(KG)	10	16	20	28.5	30	63.3
Lower Mold Weight(KG)	11	13	18	25.5	30	47.5
Machine Net Weight(KG)	21	30	38	54	62	121
Length(mm)	505	805	1105	1405	1705	2005
Height(mm)	225
Width(mm)	250
Max. Pressure(BAR)	2
Max. Temperature(℃)	200℃
Power(KW)	1.2	3.2	4.5	5.8	7	9
Weight of Machine + Flight Case(KG)	39	52	66	80	95	158
Weight of Machine + Flight Case +Wooden Crate(KG)	50	72	99	104	127	195
Shipping Crate Dimensions(mm)	800450510	1108450510	1420450510	1720450510	1990450510	2340450660
	Voltage Compatibility
110V Single Phase	✓	✓	✓	✓	×	×
220V Single Phase	✓	✓	✓	✓	✓	✓
380V Three Phase with Neural Wire	✓	✓	✓	✓	✓	✓
380V Three Phase without Neural Wire	✓	✓	✓	✓	✓	✓

Product Structure Diagram

Why Choose HOLO

Reliable Homogeneous Belt Splice Press

Although manufactured in China, the PA-Ⅱ is designed, assembled, and tested according to international industrial quality standards, comparable to European and American benchmarks.

Key advantages include:

All-in-one design for reliability and simplicity
Plug-and-play operation for quick deployment
Interchangeable base plates for versatile belt types
Fast splicing in 8–25 minutes
Strong, durable, and neat splice interface
Portable with aviation case for on-site flexibility

HOLO delivers precision, safety, and operational convenience for professional homogeneous belt splicing.

Quality Control & Factory Inspection

Each PA-Ⅱ undergoes a dual-stage factory inspection:

Pre-storage inspection
Checks mechanical stability, electrical safety, and base plate accuracy after assembly.
Pre-shipment inspection
Confirms splicing speed, joint quality, and overall performance before delivery.

This guarantees each machine meets HOLO quality standards.

Warranty & After-Sales Support

HOLO provides a 12-month warranty from shipment date.

During the warranty period:

Technical support and troubleshooting
Spare parts for quality-related issues
Remote assistance via email, phone, WhatsApp, or video guidance

Long-term technical support remains available after the warranty period.

FAQ & Support

Q1: What type of belts can the PA-Ⅱ process?

A: Homogeneous conveyor belts of various widths and specifications.

Q2: How long does a splicing operation take?

A: Fast and efficient, 8–25 minutes per splice depending on belt type and thickness.

Q3: Is the machine easy to operate?

A: Yes, plug in and start; no specialized experience required.

Q4: Can the machine be used on-site?

A: Yes, the aviation-grade carrying case allows easy transport and on-site deployment.

Q5: Are the splice joints strong and neat?

A: Yes, the PA-Ⅱ produces firm, durable, and visually neat joints.

Q6: What warranty and support does HOLO provide?

A: 12-month warranty, technical support, spare parts, and long-term after-sales service.

Contact HOLO

For technical consultation, homogeneous belt splicing solutions, or after-sales support, contact HOLO directly.
Our expert team ensures your belt splicing operations are precise, safe, and efficient.
