Fully Automatic Servo PVC PU Belt Finger Puncher TE1100-3200
High-Speed Fully Automatic Servo Finger Punching for PVC and PU Conveyor Belts
Key Features
Automatic belt feeding: efficient, continuous punching, 1 belt per minute
Multi-functional punching: straight teeth, angled teeth, double-layer teeth
Full servo control: high precision with length error within ±0.5‰
For belt type, width, and finger requirements, please submit your details via the contact form.
Application Areas
Technical Specifications
| Machine Name | 1.6m | 2.1m | 3.2m |
|---|---|---|---|
| Power | 3.5kw | ||
| Motor | 1 × 1500W Servo Motor + 2 × 750W Servo Motors | ||
| Voltage | 220v | ||
| Air Pressure | 0.5Mpa | ||
| Applicable Belts | PVC PU Teflon Rubber Core Belt | ||
| Minimum Belt Thickness | 1mm | ||
| Maximum Belt Thickness | 8mm | ||
| Tooth Punching Speed | 100 teeth per minute | ||
| Minimum Error | 1000mm error ±1mm | ||
| Belt Width | ≤1600mm | ≤2100mm | ≤3200mm |
| Machine Dimensions | 950*2650*1550 | 950*3150*1550 | 950*4250*1550 |
Why Choose HOLO
HOLO provides fully automatic servo belt punching equipment designed for high-speed, precise, and hands-free operation.
This machine helps factories and distributors achieve consistent, accurate finger punching while improving productivity.
Continuous automatic operation minimizes manual labor
Multi-functional teeth options increase production flexibility
Servo-controlled precision ensures uniform finger length
Ideal for high-volume PVC and PU conveyor belt production
Quality Control & Factory Inspection
Each Fully Automatic Servo Finger Puncher undergoes inspection before shipment, including:
Servo system calibration and accuracy testing
Punching repeatability and multi-teeth verification
Belt feeding mechanism inspection
Final operational and safety check
After-Sales Service & Support
Warranty: 1 year
Service Scope: Installation guidance, operator training, and technical consultation
Complex Applications: Custom finger types and belt specifications supported
FAQ & Support
Q1: What belt types can this machine punch?
A: Suitable for PVC and PU conveyor belts of various widths.
Q2: How fast is the punching operation?
A: Continuous automatic punching at 1 belt per minute.
Q3: What types of teeth can be punched?
A: Supports straight, angled, and double-layer teeth.
Q4: How accurate is the punching length?
A: Full servo control maintains length error within ±0.5‰.
Q5: Can HOLO support customized punching needs?
A: Yes. We provide assistance for custom finger types and belt specifications.
