Conveyor Belt Cutting Machine CA1500-4000(Z)
Industrial Conveyor Belt Cutter (Shafted Blade Design) for PU, PVC, and Fabric-Based Belts
Key Features
-
Multi-Material Compatibility: Handles PU, PVC, and fabric-based belts, thickness 1–10 mm.
-
Precise & High-Efficiency Cutting: Cuts up to 7 m/min, with minimal width deviation and smooth surfaces.
-
Flexible & User-Friendly: Operates on 220V, with caster wheels, speed adjustment, and blade setup controlled with one touch.
-
Stable Positioning: Pneumatic pressure rollers + anti-drift devices ensure cutting accuracy without belt deviation.
-
Safe & Reliable: Equipped with light curtain protection and multi-level warning systems for risk-free operation.
For belt type, thickness, and cutting requirements, please submit your details via the contact form.
Application Areas
Technical Specifications
| Machine Parameters | Shaft Drop Knife Flat Cutting Machine2m | Shaft Drop Knife Flat Cutting Machine3.2m |
|---|---|---|
| Power | 1.1kw | 1.1kw |
| Standard Voltage | 220v | 220v |
| Applicable Belts | PU/PVC/Core Belt | PU/PVC/Core Belt |
| Maximum Cutting Speed | 7m/min | 7m/min |
| Minimum Belt Thickness | 1mm | 1mm |
| Maximum Belt Thickness | 10mm | 10mm |
| Effective Width | 2050mm | 3250mm |
| Minimum Spacing | 21mm | 21mm |
| Specifications (mm) | 2500*950*1135mm | 3715*950*1135mm |
| Recommended Air Compressor Displacement | 200l/min | 200l/min |
Why Choose HOLO
HOLO develops conveyor belt cutting solutions focused on precision, safety, and efficiency.
The CA1500-4000(Z) cutter is ideal for factories and distributors who require high-speed, precise cutting for multiple belt types.
-
Covers a wide range of belt materials and thicknesses
-
High cutting speed with accurate width and smooth finish
-
Easy to maneuver and adjust for different belt widths
-
Stable operation with anti-drift and pneumatic pressure systems
-
Designed for industrial workshops and production lines
Quality Control & Factory Inspection
Each CA1500-4000(Z) machine undergoes inspection before shipment, including:
-
Cutting precision and width deviation testing
-
Pneumatic roller and anti-drift system verification
-
Motor performance and safety system check
-
Final operational and quality inspection
After-Sales Service & Support
-
Warranty: 1 year
-
Service Scope: Installation guidance, operator training, and technical consultation
-
Complex Applications: Custom belt widths, materials, and cutting setups supported
FAQ & Support
Q1: What materials can this machine cut?
A: PU, PVC, and fabric-based belts, 1–10 mm thickness.
Q2: How fast can it cut?
A: Up to 7 m/min, with precise and smooth cuts.
Q3: How is belt deviation prevented?
A: Pneumatic pressure rollers + anti-drift devices keep the belt stable during cutting.
Q4: Is it safe to operate?
A: Yes. Light curtain protection and multi-level warning system ensure operator safety.
Q5: Can HOLO customize the cutter for different belt sizes?
A: Yes. Custom widths, thicknesses, and cutting setups are supported.
